Product Introduction
Basic Product Parameters
- Material: Q235 cold-rolled steel (shelf panel: 1.5-2.0mm thick; frame column: 2.0-2.5mm thick, 30×30mm square tube)
- Load-Bearing Capacity: 800-1500kg per unit (evenly distributed); stack load (3-5 levels): 2400-7500kg
- Stackable Levels: Standard 3-5 levels (customizable up to 6 levels with reinforced base)
- Shelf Size: Standard width×depth: 1200×800mm / 1500×1000mm (fits logistics cartons/pallets); custom sizes available- Powder Coating: Epoxy-polyester hybrid powder (thickness ≥ 70μm); color customization (Pantone/RGB color matching); gloss level: 30-60% (matte/semi-gloss/high-gloss optional)
- Surface Performance: Salt spray test resistance ≥ 300 hours; scratch resistance ≥ 3H (pencil hardness test); stain resistance (oil/water stains wiped clean with a damp cloth)
Core Product Advantages
1. Brand-Aligned Visual Management: Custom powder-coating colors (100% Pantone/RGB matching) integrate racks with logistics warehouse brand image—e.g., matching corporate logo colors for unified visual identity; suitable for warehouses with client visit needs (enhancing professional brand impression).
2. High-Efficiency Stackable Storage: 3-5 levels of stable stacking (reinforced interlocking design between rack tops and bottoms) increases vertical space utilization by 200-400%; 1000㎡ warehouse can store 300+ unit cargo vs. 100+ with single-layer storage, reducing warehouse rental costs.
3. Durable & Low-Maintenance Coating: Epoxy-polyester hybrid powder coating has strong adhesion (no peeling under 500 times of cargo friction); resistance to logistics warehouse oil stains, dust, and minor chemical corrosion—annual maintenance only requires surface wiping, reducing maintenance costs by 80% vs. painted racks.
4. Safe & Stable Structure: Q235 steel frame with reinforced corner brackets (thickness: 3.0mm) prevents rack deformation under stack load; anti-slip rubber pads on the bottom of each rack increase friction with the ground (no sliding during stacking); rounded shelf edges (radius ≥ 3mm) avoid scratching forklift operators or cargo.
5. Flexible Adaptability to Logistics Cargo: Adjustable shelf height (25mm intervals) fits different sizes of logistics cargo—e.g., 200mm height for small cartons, 400mm height for bulk packages; compatible with 2.5-5 ton forklifts for easy loading/unloading of stacked racks.
Customization Service Details
1. Color Customization:
- Color Matching: 100% Pantone/RGB/Hex color matching (provide corporate logo color code or physical sample for precise matching); color options include solid colors, metallic colors (e.g., gold, silver), and matte colors (for high-end brand warehouses).
- Color Consistency: Batch color deviation ≤ ΔE 1.0 (ensuring no color difference between racks in the same order); color fastness ≥ 4-5 grade (no fading under 1000 hours of UV exposure, suitable for warehouses with natural light).
2. Size & Load Customization:
- Shelf Dimensions: Custom width (900-2000mm) and depth (600-1200mm) based on logistics cargo size—e.g., 2000×1200mm for large pallets, 900×600mm for small cartons.
- Load Upgrade: Reinforce steel thickness (shelf panel to 2.5mm, frame column to 3.0mm) to increase per-unit load to 1800-2500kg for heavy logistics cargo (e.g., small machinery parts).
- Stack Level Adjustment: Add reinforced interlocking components to increase stack levels to 6-7 levels (for high-ceiling logistics warehouses ≥ 8m height).
3. Function & Brand Customization:
- Logo Printing: Laser engraving or silk-screen printing of corporate logos on rack sides (logo size, position customizable); wear-resistant logo (no fading under 500 times of friction).
- Label Holders: Install color-matched plastic/metal label holders (consistent with rack color) for logistics cargo identification (compatible with barcode/QR code labels).
- Anti-Slip Upgrade: Add custom-color anti-slip rubber pads (matching rack color) on shelves to prevent cargo sliding—enhancing visual unity.
4. MOQ & Lead Time: Minimum order quantity for color customization: 10 units; minimum order quantity for size/function customization: 20 units; color matching confirmation takes 1-2 working days (providing color samples for client approval); production lead time: 7-10 working days (standard customization) / 10-15 working days (complex size/function customization).
Why Choose Our Company's Products
1. Professional Brand-Aligned R&D: We have 10+ years of experience in logistics storage equipment with a dedicated color customization team (5 color engineers); our powder-coating process meets ISO 12944-5 (industrial coating standard) and has successfully matched colors for 500+ logistics brands (including 20+ Fortune 500 companies).
2. Strict Quality Control for Coating & Structure: All products comply with ISO 9001 quality management system and GB/T 3325-2017 (steel furniture standard); powder coating uses 100% imported epoxy-polyester powder (no heavy metals, meets RoHS/REACH standards); each rack undergoes 100% coating adhesion test and stack load test before delivery.
3. One-Stop Brand Logistics Solution: Beyond rack customization, we provide free on-site warehouse visual design (covering 300+ cities worldwide)—e.g., planning rack color zones (matching brand color for different cargo areas), and providing 3D warehouse layout renderings to preview brand-aligned visual effects before production.
4. Reliable After-Sales Support:
- Warranty: 5-year free warranty for powder coating (no peeling, fading, or corrosion under normal use); 8-year free warranty for steel structure (frame, shelves, no deformation under rated load).
- Color Maintenance: Provide 100ml of custom-color touch-up paint for each order (free of charge) to repair minor scratches; offer professional coating maintenance guidance for long-term color retention.
- Emergency Replacement: For urgent logistics warehouse needs, we provide 48-hour emergency production for small-batch customized orders (≤ 50 units) to avoid warehouse operation delays.
5. Cost & Delivery Advantages: As a direct manufacturer with a 30,000㎡ production base and 5 automated powder-coating lines, we eliminate middleman markups—customized rack prices are 18-25% lower than distributors; standard color racks (e.g., black, gray) are in stock (5000+ units), with delivery time 2-4 working days; customized orders are delivered within 7-15 working days with door-to-door delivery.
